| Size | 63mm, 100mm, 115mm, 150mm, 250mm |
| Accuracy | 1 % , optional 0.5 % (150mm, 250mm) |
| Range | Vac to 36000 psi, Vac to 2500 bar |
| Material | SS316, SS316L, Monel, Ni Span |
Chemical & petrochemical industry, Refineries , fertilizer plants, Thermal & nuclear power generation, Machine & construction apparatus, etc.
| Size | 63 mm, 100 mm |
| Accuracy | 1.6 % (63 mm) and 1 % (100 mm) |
| Range | Vac to 23000 psi, Vac to 1600 bar |
| Material | SS316, SS316L |
Power packs, Hydraulic machinery, Pumps, Power plants, Pipelines, Transmission stations
| Size | 100mm, 115mm, 150mm |
| Accuracy | 1 % , optional 0.5 % (150mm) |
| Range | Vac to 36,000 psi, Vac to 2500 bar |
| Material | SS316, SS316L, Monel, Ni Span |
Chemical & petrochemical industry, refineries, fertilizer plants, thermal & nuclear power generation, Machine & construction apparatus, etc.
| Size | 100mm, 115mm, 150mm |
| Accuracy | 1% , optional 0.5% (150mm, 250mm) |
| Range | Vac to 15000 psi, Vac to 1000 bar |
| Material | SS316, SS316L, Monel |
Chemical & petrochemical industry, refineries, fertilizer plants, thermal & nuclear power generation, Machine & construction apparatus, etc.
| Size | 100mm, 150mm |
| Accuracy | 1.6 % |
| Range | ± 25 mbar to 2.5 bar , ± 10 IW to 30 psi |
| Material | SS316, SS316L, PTFE |
Chemical & petrochemical industry, machine & apparatus construction, food & beverage industry, pulp & paper industry, etc.
| Size | 63mm, 100mm, 115mm, 150mm |
| Accuracy | 2 % |
| Range | ± 2.5 IW to 160 IW, ± 6 mbar to 400 mbar |
| Material | SS316 |
Chemical & petrochemical industries, refineries Air conditioning, Machine and apparatus construction
| Size | 63mm, 100mm, 115mm, 150mm |
| Accuracy | 2 % |
| Range | ± 2.5 IW to 160 IW, ± 6 mbar to 400 mbar |
| Material | Brass |
Air conditioning, Machine and apparatus construnction
| Size | 100mm |
| Accuracy | 1.6% |
| Range | Vac to 10000 psi, Vac to 700 bar |
| Material | SS304 |
Power packs, Hydraulic machinery, Pumps, Power plants, Pipelines, Transmission stations
| Size | 63mm, 100mm |
| Accuracy | 1.6% |
| Range | Vac to 6000 psi, Vac to 400 bar |
| Material | Brass, SS316 |
Power packs, Hydraulic machinery, Pumps, Other vibration applications
| Size | 40mm, 50mm, 63mm |
| Accuracy | 2.5% |
| Range | Vac to 6000 psi, Vac to 400 bar |
| Material | Phosphor Bronze, Brass, SS316 |
Heating and Ventilation, Machine & Apparatus construction, Air filters & regulators, Valve positioners and compressors, etc.
| Size | 100mm, 150mm, 250mm |
| Accuracy | 2.5% |
| Range | Vac to 10,000 psi, Vac to 700 bar |
| Material | Phosphor Bronze, Brass |
Heating and Ventilation, Machine & Apparatus construction, Air filters & regulators, Valve positioners and compressors, etc.
